How to install?

1. Frist fix the pipe boby of pneumatic support to the cabinet door turning axle.

2. Keep cabinet door at open  90°  position. Let pneumatic support extend freely and

then fix the pneumatic support to the side frame of door.

Notice:

Be sure that the pipe part of the pneumatic support faces upward and the pole part

faces downward.

If you want stronger open/close force of cabinet door, you can intall at 80-100mm.

If you want weaker open/close force of cabinet door, you can intall at 50-70mm.
